Alchemist Amplifier Repairs

Alchemist Forseti

Unusual this, in the world of audio. Powered up but inputs not selectable. Found there were no volts to the regulators behind the front panel. Someone had wired a transistor to do this, but not very well. Ended up with some resistors and a Zener to perform this function, occasionally it would lock up or there would be a 7 in the small digit which, as the inputs only go up to 6 may or may not be an error code (no info found for this). Further down the time line found a fault on the protection board which hopefully cured the power on sequence.
